Description
- HIKVISION AX-PRO 96 ZONE Outdoor Alarm Starter Kit – Four Detector Passives (Wi-Fi, Ethernet, 3G & LTE)
- Outdoor Wireless Alarm Kit.
- 3G & LTE Sim, Wi-Fi Enabled & Ethernet Support.
- Fully Remote Controlled Through Mobile App.
- Plug & Play Installation.
- Add Up to 96 Zones (Can Be Purchased Separately Through AC Direct)
- Add Up to 162 Devices (Can Be Purchased Separately Through AC Direct)
- 46 Users & 1 Admin User.
- Perfect for Apartments, Private Homes, Office Buildings, Store, Warehouse & Factory.
- Whats included?
- 1 x HIKVISION AX-PRO Control Panel (96 Zone) Model CP400-1-P
- 1 x HIKVISION AX-PRO Wireless Internal Sounder Model CP402
- 2 x HIKVISION AX-PRO Wireless Keyfob Model CP405
- 4 x HIKVISION AX-PRO Wireless Outdoor Triple Signal Detector Model BD400-4
More details:
- HIKVISION AX-PRO 96 Zone Control Panel
- Model CP400-1-P
- Product Model DS-PWA96-M-WE
- The HIKVISION AX-PRO Control Panel Is the Key Element of The Alarm System.
- The HIKVISION AX-PRO Control Panel Connects Up to 96 Wireless Zones & Outputs (48 PIR Cameras Included), 48 Wireless Keyfobs, 4 Wireless Repeaters, 6 Wireless Sounders & 8 Tag Readers & Keypads.
- TCP, IP, Wi-Fi, GPRS, 3G & 4G Communication Channels.
- Plug & Play Installation.
- Uses New Generation Wireless Tri-X & Cam-X Technology for Long Distance RF Transmission.
- Two-way communication with AES-128 encryption.
- On Board Wi-Fi & LAN Port Support.
- Equipped with Single Micro SIM Slot.
- Up to 1 Installer.
- Up to 1 Admin.
- Up to 46 Users.
- Up to 32 Areas.
- Fully Remote Controlled Through Mobile App.
- Up to 96 Zones.
- Up to 48 PIR Cameras.
- Up to 8 Wireless Tag Readers & Keypads.
- Up to 6 Wireless Sounders (3 Internal & 3 External)
- Up to 48 Wireless Keyfobs.
- Up to 4 Repeaters.
- Up to 48 Tags.
- On-Board IP Camera: 4 x 7s Clips Have Their Own Storage.
- Video Verification & Remote-Control Support.
- Built-In Loudspeaker Support.
- Voice Prompt Support.
- Alarm Video Clips accessible via Email & App.
- Equipped with LED Status for Arm/Disarm, Alarm, Tamper, Fault, Cloud & Power Functions.
- Automatic Arm & Disarm Function.
- SMS message, Call & Push Notification.
- Up To 12 Hours of Battery Life (Backup Battery)
- Operating Temperature Range: -10°C to +55°C
- Dimensions: 170 x 170 x 36.8 mm
- Weight: 557.5g
- Built-In Power Supply & On-Board Battery Li.
- Included: 1x 4520 mAh Lithium Backup Battery.
- HIKVISION AX-PRO Indoor Wireless Triple Signal Detector
- Model BD400-4
- Product Model DS-PDTT15AM-LM-WE
- Wireless Motion Detector That Notifies Owner of First Signs of Intrusion.
- Plug & Play Installation.
- Made for Outdoor Use.
- Fully Remote Controlled Through Mobile App.
- Compatibility: Operates with HIKVISION AX-PRO Panel.
- Smart Environmental Control with Advanced Digital Signal Processing & 3D Optics.
- 24G Microwave to Prevent Wall Penetration.
- Alarm Signal: 0.3 – 2ms Delivery Time.
- Up To 5 Years of Battery Life (Standalone: As a Result of Being Triggered Up To 20 Times Per Day, With Camera Integrated: As a Result of Being Triggered & Completely Uploading Captures Once Per Day)
- Device Automatically Increases or Decreases Sensitivity According to Cold & Hot Weather to Accurately Detect Motion.
- Weather Resistant: IP65
- Equipped with White Light (Filter Type: 10000lux)
- LED Indicator: Blue (Alarm), Green (Top PIR), Red (Microwave), Orange (Bottom PIR), Green & Orange (Mask)
- Pet Immunity: Up To 40kg
- Motion Detect Distance: Up To 15m
- Detection Angle: 6.3°
- Up to 52 Detection Zones.
- Wireless Tri-X Transmission Technology: Transmission Range with Central Unit: Up To 1600m In an Open Space At 868MHz
- Two-way communication with AES-128 encryption.
- Operating Temperature Range: -25°C to +60°C
- Operating Humidity: 10% to 90%
- Protection Against Fraud, Jamming Detection & Tamper Resistant.
- Anti-Masking Detection.
- Dimensions: 75 x 202 x 73 mm
- Weight: 600g
- Wall Mount Option.
- Maximum Wall Mounting Height: 0.8 – 1.2m
- Main Power Supply: 3V (Battery Powered Power Supply)
- Battery Easily Replaceable with PCB Protection.
- Installation Method: Wall Mount.
- Included: 5x CR123A Batteries.
- HIKVISION AX-PRO Wireless Internal Sounder
- Model CP402
- Product Model DS-PS1-I-WE
- Wireless Internal Sounder That Notifies Owner of First Signs of Intrusion.
- Internal Sounder Used to Alert Own of Intrusion with Sound.
- Strobe Light Used for Instant Alarm Detection & Alerting of intrusion.
- Plug & Play Installation.
- Made for Indoor Use.
- Fully Remote Controlled Through Mobile App.
- Compatibility: Operates with HIKVISION AX-PRO Panel.
- Equipped with Configurable Arming/Disarming Prompt Sound & LED Indicator.
- Up To 3 Years of Battery Life (As a Result of Being Triggered Every 2 Weeks 90 Seconds for Each Triggering)
- Equipped with Buzzer – Decibel 90 to 110 dB
- Equipped with 3 Kinds of Alarm Sounds: Fire Alarm, Panic Alarm & Intrusion Alarm.
- LED Indicator: Red, Green & Amber.
- Strobe Light: Red & Blue.
- Wireless Tr-X Transmission Technology: Transmission Range with Central Unit: Up To 1600m In an Open Space At 868MHz
- Two-way communication with AES-128 encryption.
- Operating Temperature Range: -10° C to 55°C
- Operating Humidity: 10% to 90%
- Protection Against Front & Rear Tamper Resistant.
- Dimensions: 88 x 88 x 32 mm
- Weight: 169.5g
- Installation Method: Wall Mount.
- Battery Powered.
- Consumption – Static Consumption: 30 to 40 uA
- HIKVISION AX-PRO Wireless Keyfob
- Model CP405
- Product Model DS-PKF1-WE
- Up To 3 Years of Battery Life (Standby Time More Than 3 Years)
- LED Display.
- Operations: Stay/Away Arming & Disarming.
- Wireless Tri-X Transmission Technology: Transmission Range with Central Unit: Up To 900m In an Open Space At 868MHz
- Operating Temperature Range: -10°C to +55°C
- Operating Humidity: 10% to 90%
- Protection Against Fraud, Jamming Detection & Tamper Resistant.
- Dimensions: 35.2 x 63.2 x 11.3 mm
- Weight: 16g
- Battery Easily Replaceable with PCB Protection.
- Included: 1x CR2023 Battery.
- Refer to the brochure for further specification including dimensions.
- Pictures of units may differ from actual depending on the model.
- 2 Year Standard Warranty.
